| 49-inch Android Outdoor All-in-One Monitor (Air Conditioned Model) Specification Document (English Version) |
| Specications |
|
| The containment structure |
The material and feature of shell |
IP66 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
|
| Glass feature |
with 6mm Tempered explosion-proof Glass above the screen panel |
|
| LCD Panel |
Screen Size |
49 inch |
| Display area |
1073mm(H) X 604mm(V) |
| Aspect Ratio |
9:16 |
| LCD Type |
TFT-LCD |
| Max Resolution |
1920X 1080 |
| Display color |
16.7M |
| Brightness |
2000cd/㎡~2500 cd/㎡ |
| Contrast Ratio |
4000:1 |
| Viewing angle(up/down/left/right) |
178°/178°/178°/178° |
| Response Time |
6ms |
| Field Frequency |
60Hz |
| Storage temperature & Humidity |
below20℃ ~ +60℃, ≤ 90%RH |
| Touch Overlay for Interactivity |
Touch style |
Projected Capacitive Touch screen |
| Touch points |
10 points |
| Ambient light sensor |
auto dimming, with light sensor, automatically adjust the brightness. |
| Drawer-type Android Media Player box Configuration |
Processor Chip |
RK3399, six core |
| RAM |
4GB |
| Flash Memory Card |
32GB |
| Wifi and 4G |
Yes |
| Version |
Android 9.0 |
| Media Format |
Video format |
wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format |
MP3, WMA |
| Photo format |
BMP, JPEG, PNG, GIF etx |
| Onboard interface |
Network port |
RJ45, 10M/100M Adaptive Ethernet |
| HDMI |
1 |
| USB |
2 |
| Camera |
Built-in 5 Megapixel Camera with 1920X1080 Resolution |
| Speakers |
Dual side speakers for Audio |
| ECU |
Switch power supply |
Industrial Power supply |
| Waterproof speaker |
High quality waterproof 10W speaker |
| Thunder Preventer |
The tree-level lightning protection |
| Leakage protective device |
Defend Electricity Leakage |
| Timer |
Set up on/off time on day/week/month |
| Outdoor OMC system(optional) |
inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). |
|
| Problem and staus monitoring software included. |
| Touble shooting by software included. |
| Use softwae Remote Check key working performance by Group |
| Unnormal work alarm generation |
| Built-in Air conditioner for Ventilation |
Intelligent Straight ventilation Cooling system |
Intelligent cooling system, unique design of air duct and main board, automatic adjust internal temperature |
|
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically |
|
| Environment |
Working temperature |
0℃ ~ 50℃ |
| Working humidity |
5% ~ 95% |
| Working Voltage |
AC 100 ~240v , 50Hz |
| Max Power Consumption |
280W |
| Product size / Net weight |
To be determined |
| Outer Package size and Gross weight |
